By on 5.23.22 in Story Recipe, Transportation

We often receive requests around commuting patterns and answer questions like:

  • How many people live in one location but work in another?
  • How far do people travel to commute to work?
  • What models of transportation do people take to work?

Commuting data is  particularly useful for thinking about economic development, infrastructure planning, home values, climate change, and other topics.

This post will serve as our “How to Guide” on obtaining commuting data from the US Census Bureau. In it, we will cover two main methods of gathering these data:

  1. How to obtain commuting data from the 2020 5-Year American Community Survey (ACS). You would use this method if you were trying to calculate the share of households with access to at least one vehicle or the average time workers spend commuting.
  2. How to obtain commuting data using the Census Bureau’s ‘OnTheMap’ tool.

2020 American Community Survey (ACS) – Means of Transportation and Commute Time

We often use the ACS to gather and analyze 3 core variables:

  1. Percent with Vehicles Available
  2. Commute Length, in Minutes
  3. Commute Type (Means of Transportation)

Percent Vehicles Available (Table B08014)

This variable allows us to see what percentage of households have X number of cars. For example, the majority of North Carolina households (41%) have 2 vehicles, according to the 2020 5-year ACS. Additionally, 2.2% have no vehicle at all.

Commute Length, in Minutes (Table B08134)

How long are the residents in your county or neighborhood having to commute to their place of work? 43.4% of commuters across the state have less than a 20-minute travel to theirs. Do you think that is more or less than the folks in your county? Neighborhood? Well, you can use the ACS to find values for both of those geographic levels.

Commute Type – Means of Transportation (Table B08134)

The way people get to work can be critical for planning infrastructure and housing. 85.9% of commuters across NC drive by themselves. For contrast, only 1.0% use public transportation.

Table B08101 breaks down means of transportation by age and includes a “work from home” variable. Especially given the pandemic, this has become an increasingly important data point to observe and analyze.

Analyzing Variations & Disparities by Location and Race/Ethnicity

The two most impactful aspects of using the ACS for the above data is because you can break them down by location and race/ethnicity.

ACS data are available at the many levels, including Country, State, County, and Tract . This means that one can see how trends vary from one place to another. Is there a certain neighborhood that has significantly more residents who bike to work than the rest of the county where they are located? Then maybe bike lanes should be prioritized for those people. Or, at the very least, we can use these data to help determine why some areas bike more than others.

The ability to disaggregate the data by race and ethnicity allows us to spotlight disparities in our communities. Does a certain group (or groups) use more public transportation than others? Do certain demographic groups have less vehicles available, or maybe a higher percentage that have none at all? These questions can all be answered using the ACS.

Using the Census Bureau’s OnTheMap Tool

A lesser-known method of gathering commuting data from the Census Bureau is by using their OnTheMap tool.

This tool is an interactive, online application that allows you to map and extract custom data reports derived from administrative records data. What is especially unique about this site is that it combines LEHD Origin-Destination Employment Statistics (LODES) with other census data so that users can analyze hyper-local trends.

With data beginning in 2002, OnTheMap data covers 50 states and territories, allowing for analyses across the entire country. Because of the time required to process the underlying data, there is generally a longer lag between the current date and the most recent data release; the most current data stops at 2019, a 3-year delay at the time of this article.

An Example Scenario

The home screen of the tool looks like this:

A possibly lesser-known method of gathering commuting data from the Census Bureau is by using their OnTheMap tool.

Let’s take a look at how to obtain data at the county level. We will use our home county of Orange as a use case. In order to do so, we start by typing “Orange County, NC” into the search bar.

Let’s take a look at how to use the tool to obtain data at the county level. We will use our home county of Orange as a use case. In order to do so, we start by typing “Orange County, NC” into the search bar.

Notice the different geographic levels that you can view data at. As mentioned above, we are focusing on county-level data. Clicking on the desired county name (bolded above) will zoom the map to that location and prompt a tooltip, as well.

Selecting “Perform Analysis on Selection Area” prompts a window that allows us to select the year (or years) and the variables we want to view.

Selecting “Perform Analysis on Selection Area” prompts a window that allows us to select the year (or years) and the variables in which we want to view.

You’ll notice that there are 4 sections in this pop-up window:

  • Home/Work Area
    • This determines whether or not you are pulling data on people who live in the selection area (in this case Orange County) or people who work in the area (whether or not they live there).
    • For the type of analysis we are doing in this example, this filter actually becomes obsolete, but is a very important distinction to be aware of for the rest of the variables
  • Analysis Type
    • This decides which indicator you are going to be asking the tool to access
    • You’ll notice that variables that can be disaggregated by Labor Market Segment (age, income, or industry groupings) and/or a location type have drop downs that allow you to do specify which group or geographic location is of interest.
    • We will be using the Inflow/Outflow variable for this example
  • Year
    • Use this checkbox to select one or more years for your data
    • Notice that 2019 is the most recent year of data at the time of this post, a roughly 3-year lag
  •  Job Type
    • This filters the data by the 4 types of jobs listed (All Jobs, Primary Jobs, Private Jobs, and Private Primary Jobs)
      • Primary Job refers to the highest paying job for an individual worker for the year being analyzed
      • Private Job focuses only on private-sector jobs
    • We are using Primary Jobs for this example.

As the previous screenshot shows, we will be looking at the Inflow/Outflow data of Orange County for 2019. After selecting “Go” on the pop-up window, your screen should look like this:

What this map, and the graphics on the right, are telling you is how many people commute into, out of, and within Orange County. In other words:

  • 48,849 people commute into Orange County for work
  • 38,103 Orange County residents commute elsewhere
  • 19,851 Orange County residents work within the county

On the right hand side of the screen, it shows these statistics in an alternative form: the dark green are individuals who work in Orange County but live elsewhere; the lightest green are the individuals who live in Orange County and work elsewhere; and the intersection represents individuals who live and work in Orange County. In total, there were 68,700 people employed in Orange County in 2019 (based on Primary Jobs) and 71% commuted from another county. Of the 57,954 total people living in Orange County, 66% worked at a location outside of the county.

On the left hand side of the screen, the tool allows you to export the geographic data, pictures of the charts (on the right), and also view a “detailed report,” which then prompts a window allowing you to view the data in a neat chart. This window also allows you to download the data as a PDF and/or Excel file.

This type of analysis frequently prompts additional questions, such as: where are individuals who are working in Orange County commuting from? where do out-commuters go to work? These questions, and many more, can be answered by changing the analysis type and other filter settings as detailed above.

Note: The data used to generate work locations are derived from unemployment insurance records, which contain addresses for both the employer and employee. As a result, if a resident telecommutes (works from home), they may generate a data point that says they commute from Chapel Hill to Los Angeles. This would be because the company is based in California, but the employee resides and telecommutes from North Carolina.
